Detail produk:
|
| Nomor Bagian: | ADUM6410BRSZ-RL7 | Pabrikan: | Perangkat Analog Inc. |
|---|---|---|---|
| Keterangan: | DGTL ISO 3.75KV 4CH RS232 24SSOP | kategori: | Isolator Digital |
| Keluarga: | Isolator Digital | Seri: | iCoupler® |
| Part Status | Active |
|---|---|
| Technology | Magnetic Coupling |
| Type | RS232 |
| Isolated Power | Yes |
| Number of Channels | 4 |
| Inputs - Side 1/Side 2 | 4/0 |
| Channel Type | Unidirectional |
| Voltage - Isolation | 3750Vrms |
| Common Mode Transient Immunity (Min) | 75kV/µs |
| Data Rate | 150Mbps |
| Propagation Delay tpLH / tpHL (Max) | 13ns, 13ns |
| Pulse Width Distortion (Max) | 3ns |
| Rise / Fall Time (Typ) | 2.5ns, 2.5ns |
| Voltage - Supply | 1.7 V ~ 5.5 V |
| Operating Temperature | -40°C ~ 105°C |
| Package / Case | 24-SSOP (0.209", 5.30mm Width) |
| Supplier Device Package | 24-SSOP |
| Shipment | UPS/EMS/DHL/FedEx Express. |
| Condtion | New original factory. |
